Transmission Line Models

The following is a complete list of transmission line models available in SimPCB Lite.

Single-ended Transmission Lines

Surface Microstrips

• Surface microstrip (SM-1B)



• Coated microstrip (CM-1B)



• Surface microstrip (SM-2B)



• Coated microstrip (CM-2B)



Embedded Microstrips and Offset Striplines

• Embedded microstrip (EM-1B1A)



• Offset stripline (OS-1B1A)



• Embedded microstrip (EM-1B2A)



• Offset stripline (OS-1B2A)



• Embedded microstrip (EM-2B1A)



• Offset stripline (OS-2B1A)



• Embedded microstrip (EM-2B2A)



• Offset stripline (OS-2B2A)



Differential Pairs

Edge-Coupled Surface Microstrips

• Edge-coupled surface microstrip (ECSM-1B)



• Edge-coupled coated microstrip (ECCM-1B)



• Edge-coupled surface microstrip (ECSM-2B)



• Edge-coupled coated microstrip (ECCM-2B)



Edge-Coupled Embedded Microstrips and Offset Striplines

• Edge-coupled embedded microstrip (ECEM-1B1A)



• Edge-coupled offset stripline (ECOS-1B1A)



• Edge-coupled embedded microstrip (ECEM-1B2A)



• Edge-coupled offset stripline (ECOS-1B2A)



• Edge-coupled embedded microstrip (ECEM-2B1A)



• Edge-coupled offset stripline (ECOS-2B1A)



• Edge-coupled embedded microstrip (ECEM-2B2A)



• Edge-coupled offset stripline (ECOS-2B2A)



Coplanar Single-ended Transmission Lines

Surface Coplanar Waveguides

• Surface coplanar waveguide (SCW-1B)



• Coated coplanar waveguide (CCW-1B)



• Surface coplanar waveguide with ground (SCWG-1B)



• Coated coplanar waveguide with ground (CCWG-1B)



• Surface coplanar waveguide (SCW-2B)



• Coated coplanar waveguide (CCW-2B)



• Surface coplanar waveguide with ground (SCWG-2B)



• Coated coplanar waveguide with ground (CCWG-2B)



Embedded Coplanar Waveguides and Offset Coplanar Waveguides

• Embedded coplanar waveguide (ECW-1B1A)



• Embedded coplanar waveguide with ground (ECWG-1B1A)



• Offset coplanar waveguide (OCW-1B1A)



• Embedded coplanar waveguide (ECW-1B2A)



• Embedded coplanar waveguide with ground (ECWG-1B2A)



• Offset coplanar waveguide (OCW-1B2A)



• Embedded coplanar waveguide (ECW-2B1A)



• Embedded coplanar waveguide with ground (ECWG-2B1A)



• Offset coplanar waveguide (OCW-2B1A)



• Embedded coplanar waveguide (ECW-2B2A)



• Embedded coplanar waveguide with ground (ECWG-2B2A)



• Offset coplanar waveguide (OCW-2B2A)



Coplanar Differential Pairs

Coplanar Differential Surface Waveguides

• Diff surface coplanar waveguide (DSCW-1B)



• Diff coated coplanar waveguide (DCCW-1B)



• Diff surface coplanar waveguide with ground (DSCWG-1B)



• Diff coated coplanar waveguide with ground (DCCWG-1B)



• Diff surface coplanar waveguide (DSCW-2B)



• Diff coated coplanar waveguide (DCCW-2B)



• Diff surface coplanar waveguide with ground (DSCWG-2B)



• Diff coated coplanar waveguide with ground (DCCWG-2B)



Coplanar Differential Embedded Waveguides and Offset Waveguides

• Diff embedded coplanar waveguide (DECW-1B1A)



• Diff embedded coplanar waveguide with ground (DECWG-1B1A)



• Diff offset coplanar waveguide (DOCW-1B1A)



• Diff embedded coplanar waveguide (DECW-2B1A)



• Diff embedded coplanar waveguide with ground (DECWG-2B1A)



• Diff offset coplanar waveguide (DOCW-2B1A)



• Diff embedded coplanar waveguide (DECW-1B2A)



• Diff embedded coplanar waveguide with ground (DECWG-1B2A)



• Diff offset coplanar waveguide (DOCW-1B2A)



• Diff embedded coplanar waveguide (DECW-2B2A)



• Diff embedded coplanar waveguide with ground (DECWG-2B2A)



• Diff offset coplanar waveguide (DOCW-2B2A)
